ErgoVu-30 Table / Wall Mount Inspection Booths

The ErgoVu-30 LED series of wall and table mount manual inspection booths are designed for areas that have space constraints. The booths are designed to be used on a table top or can be wall mounted. Wall mounted versions can also have motorized lift to accommodate all height inspection operators. The WB series utilizes the same LED light sources for top and/or bottom illumination as our ergonomic full size motorized booths. Our custom designed and built stations are in use at major pharmaceutical and biomedical companies and have a proven high reliability record.

Our inspection booths can be custom configured to meet your exact requirements of light output and spectrum. Illumination intensity is variable with micro-adjusters for precise light levels. The constant current design maintains consistent color temperature and assures long LED life.

Our LED illumination system saves energy and cost over its long service life using 20% of the power of a typical fluorescent illumination booth and offering up to 40,000 hrs LED life. This reduces the need for constant lamp replacement and significantly reduces the load on your facility HVAC system.

All systems are designed and built in the USA using only the finest materials for a long operational life.

We offer many optional accessories to complete the package, from LED custom lighting to microscope and optical systems for inspection, rework, and micro-assembly tasks. We can also custom build stations to fit your needs.

APPLICATIONS

• Pharmaceutical
• Biomedical
• Semiconductor
• Micro-assembly
• Re-work
• Cleanroom applications

Ideal choice for:

• Vial inspection and fill laboratories
• Scientific laboratories
• Biomedical sub-assembly build
• Semiconductor FAB
• Electronic re-work stations

FEATURES

• LED High Intensity Column Illumination (visual inspection systems only)
  - TOP and/or BOTTOM lighting options
  - Fully adjustable regulated output with µFine intensity controls
  - Non-glare design for operator comfort
  - Earth friendly light source, no mercury (used in fluorescent designs)
  - Low energy use, Long consistent life
  - Highest quality, color matched HB-LED's; approx. 5500°K color temp
• CLEAN ROOM compatible materials and surfaces
  - Modular high strength aluminum framing
  - Sound deadening enclosure panels; Trespa type material or aluminum/honeycomb option
  - Durable grey neutral low-sheen finish
  - Corian® type table material; optional Trespa, stainless steel or hard-anodize aluminum
• ERGONOMIC user design
  - Black/white contrast plate with vertical position control; telescope,tilt options
  - Optional Motorized wall mount ; silent, smooth motion
• Built to last - only top quality components used
  - Made in USA
  - Customizable to meet your requirements

MODELS

TABLE Mount Booth – bottom illumination (ErgoVu-30B)

TABLE Mount Booth – top illumination (ErgoVu-30T)

TABLE Mount Booth – top and bottom illumination (ErgoVu-30TB)

Contact us for wall mount and motorized lift options
